Nitecore TM Series Li-ion Battery Pack (NBP68HD)
Nitecore TM Series Li-ion Battery Pack (NBP68HD) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
The latest Nitecore NBP68HD battery pack is a high drain battery designed as a replacement for some of the Nitecore TM series of torches and is compatible with the TM15, TM26, TM26GT, TM28, TM36, TM36 Lite, TM38 and TM38 Lite torches.
The battery pack is made up of eight 18650 3.7 V lithium-ion batteries, therefore doubling the usual run-time of the torch.
The NBP68HD can be charged three ways. The first way is by being attached to a TM model that features a charging port and is designed to charge the battery. The second and third way is via two integrated charging ports when the battery pack is unattached from a torch. One is a standard 2 A port (3.5 mm) and a the other is a larger 4 A port (4.0 mm) for rapid charging.
The 2 A port can be used with the charging lead that is supplied with a TM15, TM26/TM26GT, TM28, TM36 or TM38 torch.
The blue light will blink 5 times time per second to indicate a normal state of charge
When charging is 98% complete, the blue light will blink slowly
When charging is complete, the blue light will be permanently illuminated
Designed for the Nitecore TM series torches
Electronically protected against over charge and over discharge.
Capable of more than 500 charge-discharge cycles.
Capacity: 98 Wh (8 x 3.7 volt 18650 cells)
Voltage: 3.7 V
Charging current: 2 A (15 hours to full charge) or 4 A (8 hours to full charge)
Charging Ports: 1 x 3.5 mm port at 12 V dc and 1 x 4.0 mm port at 12 V dc
Weight: 587 grams
Size: 157 mm (L) x 50 mm (D)
Warranty: 1 year
1. Never expose an NBP68HD to water or fire
2. To extend battery life, it is recommended that a NBP68HD is charged every three months when unused for long periods
Important Safety Information
Lithium-ion batteries should never be left charging unattended under any circumstances. The user must have knowledge of how to charge and discharge lithium-ion batteries before using them. For more information please click here. Always use a charger that is designed to recharge the particular lithium-ion cell that you wish to recharge. Never use a DC adaptor to charge lithium-ion batteries. We are NOT responsible for any damage that is caused by the misuse of lithium-ion batteries. We recommend charging any Lithium-ion cell on a metal surface or other non-flammable surface.
Packaging and Contents
Supplied in retail packaging and contains:
Nitecore NBP68HD battery pack x 1
