Xtar B20 1200 LED Torch Kit

The Xtar B20 1200 is a powerful LED torch with a maximum output of 1200 lumens.

Featuring a Cree XM-L2 LED and a lithium-ion rechargeable battery, the B20 1200 delivers a stunning, balanced beam capable of illuminating at a maximum distance of 240 metres.

The supplied lithium-ion 4900 mAh rechargeable battery can be charged in the supplied SC1 charger with the USB cable provided.

The Xtar B20 1200 features single button operation controlling strobe mode plus 4 lighting levels of low, mid, high and turbo, making the light highly versatile, with a choice of outputs and run-times to suit your task. The memory function remembers the last brightness setting used (except strobe).

Supplied with a lanyard for use in the field.

Note: Only use a 21700 protected lithium-ion battery (as supplied) in the Xtar B20 1200.

Operational Modes

Low: 30 lumens; 80 hours run-time
Mid: 270 lumens; 13 hours, 30 minutes run-time
High: 600 lumens; 5 hours, 30 minutes run-time
Turbo: 1200 lumens; 3 hours, 30 minutes run-time*
Strobe: 361 lumens

Note: *The overheat protection will automatically drop the turbo brightness level to the high brightness level after 5 minutes, therefore this is an accumulated run-time.

The above parameters were lab tested to ANSI standards using an Xtar 21700 battery and are approximate. Outputs may vary between torches, batteries and environments.

Technical Details

Type: Hand Held Torch
Operating Modes: Low / Mid / High / Turbo / Strobe
Luminous Flux: Up to 12000 lumens
Lamp Type: Cree XM-L2
Beam Range: Up to 240 m
Batteries Required: 1 x 21700 lithium-ion (included)
Overall Length: 146.3 mm
Head Diameter: 34.5 mm
Barrel Diameter: 26.8 mm
Weight: 122 grams (excluding battery)
Body Colour: Black
Body Material: 6061 aircraft-grade aluminium alloy with anti-corrosive finish
Switch Type: End cap switch
Impact Resistance: 1.2 m
Environmental: Waterproof to IPX8 standard (submerged 1.5m)
Warranty: 2 years

Packaging and Contents

Supplied in retail packaging and contains:
Xtar B20 1200 LED torch x 1
Xtar SC1 charger (with USB cable) x 1
Xtar 4900 mAh 21700 lithium-ion battery x 1
Lanyard x 1
Spare O-ring x 1
Manual x 1
